3D Bioprinting Organs Based on Microscopic Imaging

Image of eye 3D Bioprinting of Organs with Cellular Accuracy

3D Bioprinting of Organs with Cellular Accuracy

This is incredible. For the first time, researchers managed to make intact human organs transparent. Using microscopic imaging they could reveal underlying complex structures of the see-through organs at the cellular level. Resulting organ maps can serve as templates for 3D bioprinting technologies. In the future, this could lead to the creation of on demand artificial organs for many patients in need. The findings published in Cell joined forces from Helmholtz Zentrum München, Ludwig Maximilians University Munich (LMU), and Technical University of Munich (TUM).

From an article in The Daily Star.

In biomedical research, seeing is believing. Deciphering the structural complexity of human organs has always been a major challenge due to the lack of technologies to image them at the cellular level. Recent developments in tissue clearing allowed researchers to obtain first cellular views of intact transparent mouse organs in 3D. These methods, however, were not applicable to human organs.

Human organs are particularly stiff due to accumulation of insoluble molecules including collagen in tissues that have grown for years or even decades. Thus, traditional detergents that are used for making mouse organs transparent do not work on human organs, particularly adult ones. “We had to change our approach completely and start from scratch to find new chemicals which can make human organs transparent,” says Shan Zhao, PhD student at Helmholtz Zentrum München and first author of the study. After exhausting trials, the team discovered that a detergent called CHAPS could make small holes throughout the entire stiff human organs. CHAPS allows additional solutions to travel deep into centimetres-thick human organs and convert them into a transparent structure.

After making the human organs transparent, which were obtained post mortem from Prof Ingo Bechmann’s lab at the University of Leipzig, the team had to tackle additional challenges for both organ imaging and the analysis of the large amount of resulting data. First, they developed a new laser-scanning microscope with a large sample holding capacity called “Ultramicroscope Blaze” in collaboration with Miltenyi Biotec. This microscope enabled imaging of human organs as large as the kidney. Next, together with Prof. Bjoern Menze from TUM, the team developed deep learning algorithms to be able to analyse hundreds of millions of cells in 3D.

The researchers named this new technology SHANEL (Small-micelle-mediated Human orgAN Efficient clearing and Labelling). “SHANEL can develop into a key technology for mapping intact human organs in the near future. This would dramatically accelerate our understanding of organs such as the brain, their development and function in health and disease,” explains Dr. Ali Ertürk, Director of the Institute for Tissue Engineering and Regenerative Medicine at Helmholtz Zentrum München.

For the complete article click here.

Note – If you liked this post click here to stay informed of all of the 3D laser scanning, geomatics, UAS, autonomous vehicle, Lidar News and more. If you have an informative 3D video that you would like us to promote, please forward to editor@lidarnews.com and if you would like to join the Younger Geospatial Professional movement click here.
